Color quantization (Octree)
Reduce an image’s palette using an octree.
Rebol [
title: "Rosetta code: Color quantization (Octree)"
file: %Color_quantization-octree.r3
url: https://rosettacode.org/wiki/Color_quantization
]
octree-quantize: function/with [
img [image! file! url!]
n-colors [integer!]
][
unless image? img [img: load img]
quantizer: make-octree-quantizer
;; Downsample to 25% of pixels for tree building - dramatically faster with
;; minimal palette quality loss since distribution is well represented by a sample
sm-img: resize/filter img 25% 'box
;; First pass - count color frequencies
freq: make map! 32768
foreach color sm-img [
freq/:color: either p: freq/:color [p + 1][1]
]
;; Second pass - only add frequent colors to the octree
foreach color sm-img [
if freq/:color > 1 [
add-color quantizer color
]
]
palette: make-palette quantizer n-colors
;; Map each pixel to its nearest palette color.
forall img [
idx: get-palette-index quantizer img/1
img/1: palette/:idx
]
reduce [img palette]
][
;; Maximum octree depth - at depth 8 each node represents a unique 24-bit color
;; (8 bits per channel, one bit inspected per level)
make-octree-node: func [level parent /local node] [
node: object [
;; Accumulated channel sums and pixel count for average color calculation
red: green: blue: pixel-count: 0
palette-index: 0 ;; assigned during make-palette
children: array 8 ;; up to 8 children, one per RGB bit at this level
]
;; Leaf-level nodes (level 7) are not registered since they won't be merged
if level < 7 [
add-level-node parent level node
]
node
]
; Iteratively collect all leaf nodes (nodes with pixel-count > 0) under `node`
get-leaf-nodes: function [node] [
leaf-nodes: copy []
stack: clear []
foreach child node/children [
if child [append stack child]
]
while [not empty? stack] [
current: take stack
either current/pixel-count > 0 [
append leaf-nodes current
][
foreach child current/children [
if child [append stack child]
]
]
]
leaf-nodes
]
;; Walk the tree to find the palette index assigned to `color`.
;; At a leaf, return its index. Otherwise, compute which child to descend into
;; by extracting one bit per channel at the current level to form a 3-bit index.
;; If the exact child was pruned during palette reduction, fall back to the first
;; available sibling.
get-palette-index-for-color: function [node color level] [
; Walk the tree iteratively until we reach a leaf (pixel-count > 0)
while [node/pixel-count = 0] [
index: 1
mask: 128 >> level
unless zero? color/1 & mask [index: index + 4] ; bit 2
unless zero? color/2 & mask [index: index + 2] ; bit 1
unless zero? color/3 & mask [index: index + 1] ; bit 0
++ level
;; If exact child was pruned, fall back to first available child
either node/children/:index [
node: node/children/:index
][
foreach child node/children [
if child [node: child break]
]
]
]
node/palette-index
]
;; Merge all children of `node` into the node itself, making it a leaf.
;; Accumulates children's color sums and pixel counts into the parent.
;; Returns the net reduction in leaf count: (number of children merged) - 1,
;; because the parent itself becomes a new leaf.
remove-leaves: function [node] [
result: 0
foreach child node/children [
if child [
node/red: node/red + child/red
node/green: node/green + child/green
node/blue: node/blue + child/blue
node/pixel-count: node/pixel-count + child/pixel-count
++ result
]
]
result - 1
]
;; Compute the average color for a leaf node by dividing accumulated
;; channel sums by the total pixel count
get-color: func [node] [
make tuple! reduce [
node/red / node/pixel-count
node/green / node/pixel-count
node/blue / node/pixel-count
]
]
get-pixel-count: func [node] [
result: 0
stack: clear []
foreach child node/children [if child [append stack child]]
while [not empty? stack] [
if current: take stack [
either current/pixel-count > 0 [
result: result + current/pixel-count
][
append stack current/children
]
]
]
result
]
;; Create and initialise a new octree quantizer.
;; `levels` holds one block of nodes per depth level, used during palette reduction.
;; `leaf-count` tracks the current number of leaves without requiring a tree walk.
make-octree-quantizer: func [/local quantizer] [
quantizer: context [
levels: array/initial 8 []
root: none
leaf-count: 0
;; caches:
color-node: make map! 16384
color-index: make map! 65536
]
quantizer/root: make-octree-node 0 quantizer
quantizer
]
;; Register `node` at `level` in the quantizer so it can be found during reduction
add-level-node: func [quantizer level node] [
append (pickz quantizer/levels level) node
]
get-leaves: func [quantizer] [
get-leaf-nodes quantizer/root
]
;; Add `color` to the octree. Uses color-node cache to skip tree
;; traversal for already-seen colors, only walking the tree on first
;; encounter of each unique color. At each level, a 3-bit index derived
;; from one bit per RGB channel selects the child. A new leaf is counted
;; the first time a node receives a pixel at max depth.
add-color: function [quantizer color [tuple!]] [
unless node: quantizer/color-node/:color [
;; First time seeing this color - traverse/build the tree path
node: quantizer/root
level: 0
while [level < 8] [
index: 1
mask: 128 >> level
unless zero? color/1 & mask [index: index + 4]
unless zero? color/2 & mask [index: index + 2]
unless zero? color/3 & mask [index: index + 1]
unless node/children/:index [
node/children/:index: make-octree-node level quantizer
]
node: node/children/:index
++ level
]
;; Count new leaf (pixel-count = 0 means this node hasn't been seen before)
if all [
node/pixel-count = 0
level >= 8
][ quantizer/leaf-count: quantizer/leaf-count + 1 ]
;; Cache the node so future occurrences of this color skip the traversal
quantizer/color-node/:color: node
]
;; Accumulate color data regardless of cache hit or miss
node/red: node/red + color/1
node/green: node/green + color/2
node/blue: node/blue + color/3
node/pixel-count: node/pixel-count + 1
]
;; Build a palette of at most `color-count` colors by reducing the octree bottom-up.
;; Iterates levels from deepest to shallowest, merging sibling leaves into their
;; parent until the leaf count fits within the target. Then assigns palette
;; indices to remaining leaves and records their average colors.
make-palette: function [quantizer color-count] [
palette: copy []
palette-index: 0
leaf-count: quantizer/leaf-count
for level-index 8 1 -1 [
level-nodes: quantizer/levels/:level-index
unless empty? level-nodes [
foreach node level-nodes [
if leaf-count <= color-count [break]
;; count how many children this node has (= reduction + 1)
children-count: 0
foreach child node/children [if child [++ children-count]]
if (leaf-count - children-count + 1) >= color-count [
leaf-count: leaf-count - (remove-leaves node)
]
]
if leaf-count <= color-count [break]
quantizer/levels/:level-index: copy []
]
]
;; Assign palette indices to remaining leaves and record their average colors
foreach node get-leaves quantizer [
if palette-index >= color-count [break]
if node/pixel-count > 0 [append palette get-color node]
node/palette-index: palette-index
++ palette-index
]
palette
]
;; Look up the palette index for `color` by traversing the (possibly reduced) tree
get-palette-index: function [quantizer color] [
unless index: quantizer/color-index/:color [
quantizer/color-index/:color: index:
get-palette-index-for-color quantizer/root color 0
]
index + 1
]
]
;; Download the original image if does not exists.
unless exists? %Quantum_frog.png [
write %quantum_frog.png
read https://static.wikitide.net/rosettacodewiki/3/3f/Quantum_frog.png
]
foreach [colors output-name] [
16 %Quantum_frog-octree-16-colors.png
32 %Quantum_frog-octree-32-colors.png
][
;; Quantize to N colors
time: delta-time [
set [img colors] octree-quantize %Quantum_frog.png colors
]
print ["Time to compute:" time]
;; Display all used colors
print ["The" length? colors "colors used:"]
probe new-line/all colors true
save output-name img ;; Save the result
browse output-name ;; Display the image in a browser
]
